Mobile Communication System FDD-LTE: B1/B3/B7/B8/B28 TDD-LTE:B40/B41 WCDMA:B1/B8 GSM:B3/B8 Speed Rate FDD-LTE DL/UL 150Mbps/50Mbps DC-HSPA+ DL/UL 43.1 Mbps/5.76 Mbps Display 1.44' Color OLED,128X64 Pixels 4G/3G/2G Network Status Connection Status Battery Status New SMS Status Mobile operator name WPS Roaming Status Internet Status Battery Capacity: 2100 mAh Working time:6 hours (normal network situation) External Interface MicroSD slot ,Support(Up to 32GB) SIM slot Micro-USB, 5V/1A for charger and storage data sharing Button Power WPS Reset Standard&Protocol IEEE 802.11n?IEEE 802.11g?IEEE 802.11b Antenna Internal Two antennas Power Input Voltage Range(VDC): DC 5V 1A Wireless Link Rate 802.11 b/g/n Frequency Range 2.4-2.4835GHz Basic Function Client Filter SSID,Broadcast Channel Wireless Security WPA-PSK/WPA2-PSK WPA/WPA2 WEP Internet Connection Type LTE FDD/UMTS/WCDMA/GSM APP management IOS/Android Working Mode 3G/4G Router Certification CE Granted ROHS Granted Temperature Operating Temperature: 0?~40? Storage Temperature: -30?C~70?C Humidity Operating Humidity: 10% ~ 90% RH Non-condensing Storage Humidity: 5% ~ 90% RH Non-condensing Default Settings Login IP Address: 192.168.0.1 Login User Name/Password: admin/admin SSID: Tenda_xxxxxx (where "xxxxxx" represents the last sit characters of device MAC address) Package Content 4G185 USB Cable Quick Install Guide Battery
